| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) |
Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm2) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) | Encoder Resolution (P/R) |
| 63SSTT 482030 |
3 | 8 | 48 | 3000 | 0.64 | 200 | 5.5 | 16.5 | 1.92 | 0.25 | 0.11 | 10.5 | 0.2 | 0.4 | 68 | 0.6 | 1000, 1024, 2500/17bit, 23bit |
| 63SSTT 484030 |
3 | 8 | 48 | 3000 | 1.27 | 400 | 11 | 33 | 3.81 | 0.45 | 0.11 | 10.5 | 0.4 | 0.6 | 82 | 1.0 | |
| 63SSTT 2202030 |
3 | 10 | 220 | 3000 | 0.64 | 200 | 1.45 | 4.35 | 1.92 | 0.25 | 0.44 | 29 | 10 | 11 | 68 | 0.6 | |
| 63SSTT 2204030 |
3 | 10 | 220 | 3000 | 1.27 | 400 | 2.9 | 8.7 | 3.81 | 0.45 | 0.44 | 29 | 2.2 | 5.5 | 82 | 1.0 |
*Note: We can manufacture products according to customer's requirements.
